Kubota GL Series Generator

Kubota diesel generators GL Series offers a space saving and environmentally friendly design. Powered by vertically mounted Kubota SUPER MINI diesel engines, they feature compact size, low body design and very low noise levels.

Kubota Diesel Generators GL Series Standard Features

  • The generator and the engine are direct-coupled to ensure a more reliable power supply with minimum power loss.
  • Skewed rotor and damper winding helps keep waveform distortion to a minimum, protects the generator during short circuits, regulates voltage fluctuations during condensive loads, and withstands load fluctuations during condensive and non-linear loads.
  • The compact design of the LOWBOY II Series is based on the previous compact two-pole horizontal type diesel engine generator. Even though this series is powered by vertical type diesel engines, the height is kept as low as the previous LOWBOY by direct coupling the engine crankshaft with the cooling fan.
  • Four design elements help reduce the overall noise levels: (1) The large capacity radiator successfully reduces fan related noise by direct coupling its crankshaft with the slower-speed fan; (2) The large capacity built-in muffler helps reduce exhaust related noise; (3) The longer air cleaner hose reduces air suction related noise; (4) The ideally placed inlet vent and its improved design reduce noise coming from the enclosure’s opening.
  • The LOWBOY Series’ large capacity (28L) fuel tank enables longer continuous operation on a single tank of fuel.
  • Special forklift openings on the base of the machine, and the one-point lifting eye enhanced transportability.
  • Access terminals for Automatic Transfer Switches (not supplied) are located behind the control panel for easy wiring.
  • Single side maintenance – oil, fuel, battery, and cooling water are all located on one side for easy maintenance.
  • Large capacity oil pan helps stretch the oil change intervals.
  • Direct-coupled design eliminates the time needed to adjust or replace the cog-belt by direct coupling the generator and the engine.
  • Standard double element air cleaners are ideal for heavy duty applications in dusty environments.
  • In addition to the overall circuit protector, each receptacle also has a circuit protector that will shut the engine down to prevent it from overcurrent damages.
  • Output connection cover stops the engine immediately when it is opened up during operation.
  • Automatic shutdown system automatically shuts the engine down when it senses the engine coolant temperature rising excessively or the oil pressure dropping below a safe level.
  • Starter safety relay prevents the starter from engaging again once the engine starts up.
  • Optional 2-wheel kit (pictured below) and remote control kit available.
Kubota GL Generator shown with optional wheel kit
Shown above: Kubota GL Generator mounted on optional wheel kit.

Note: EPS is factory-authorized to sell Kubota generators in the following U.S. states: Alabama, Delaware, District of Columbia, Florida, Georgia, Kentucky, Maryland, New Jersey, North Carolina, Pennsylvania, South Carolina, Tennessee (eastern), Virginia and West Virginia. To purchase Kubota generators from locations outside of this territory, please contact the factory or your local Kubota distributor.

Kubota GL Series Diesel Generator Specifications

Model kW Volts Phase Poles Noise (db)
GL-7000 7.0 120/240 1 2 66
GL-7000TM (Terminal Mount) 7.0 120/240 1 2 66
GL-11000 11.0 120/240 1 2 68
GL-11000TM (Terminal Mount) 11.0 120/240 1 2 68
Specifications subject to change without notice.
